Name: Chemical Rotary Kiln Dryer 0.35r/MinDust Removal Rotary Kiln Electric Furnace
Brand: Henan Zoomline Machinery Manufacturing co. Ltd
SKU: customization
Availability: InStock

Home > products > Rotary Kiln >

Chemical Rotary Kiln Dryer 0.35r/MinDust Removal Rotary Kiln Electric Furnace

Chemical Rotary Kiln

rotary kiln dryer 0.35r/min

0.35r/min rotary kiln electric furnace

Place of Origin:

henan China

Brand Name:

Zoomline

Model Number:

customization

Request A Quote

Product Details

Slope:

3.5-4%

Rotating Speed:

0.35-3.55r/min

Installation:

Provided

Highlight:

Chemical Rotary Kiln

rotary kiln dryer 0.35r/min

0.35r/min rotary kiln electric furnace

Payment & Shipping Terms

Zinc Oxide Rotate Kiln Equipment 440V Rotary Calcination Furnace Transmission Device

Get Best Price

$Good price 0.5 - 2.47r/Min Pelletizing Rotary Kiln Refractory Kiln High Alumina Bricks online$ Video

0.5 - 2.47r/Min Pelletizing Rotary Kiln Refractory Kiln High Alumina Bricks

Get Best Price

Video

Calcium Aluminate Rotary Kiln Transmission Device Rotary Calciner 3.55r/Min

Get Best Price

Metallurgical 200kg/H Rotary Kiln Electromagnetic Heating Calciner Kiln

Get Best Price

86-0391

Contact Now

Product Description

Chemical Rotary Kiln Dryer 0.35r/Min Dust Removal Rotary Kiln Electric Furnace

Key Specifications

Attribute	Value
Slope	3.5-4%
Rotating Speed	0.35-3.55r/min
Installation	Provided

Product Overview

Chemical rotary kiln equipment with optional dust removal, feeding and discharging equipment. This industrial kiln is primarily used for calcining chemical clinker, available in both dry and wet production variants.

Industrial Applications

Magnetization roasting of chromium for lean iron ore in steel plants
Oxidation roasting of nickel iron ore
Roasting of high-alumina bauxite in refractory plants
Processing of aluminum hydroxide in aluminum plants
Roasting of chromium ore sand and powder in chemical plants

Performance Features

Controllable axial movement: Steel cylinder with wheel belt support and mechanical/hydraulic stop wheels for precise positioning
Variable speed operation: Gear-driven rotation with adjustable speed settings
Easy maintenance: Includes auxiliary drive for low-speed rotation during service
Effective sealing: Specialized kiln head and tail seals prevent air infiltration and dust leakage

Technical Specifications

Model	Barrel Diameter (mm)	Barrel Length (mm)	Slope (%)	Capacity (t/h)	Speed (r/min)	Motor Power (kW)	Weight (t)
YZ1225	1200	25000	4	3	0.35 - 3.55	15	34
YZ1632	1600	32000	4	3.5	0.53 - 5.25	22	46.82
YZ1636	1600	36000	4	1.2 - 1.9	0.26 - 2.61	22	51.023
YZ1828	1800	28000	4	4	0.28 - 2.84	30	59.39
YZ1845	1800	45000	4	4.5	0.28 - 2.84	30	80
YZ1939	1900	39000	4	1.6 - 3.4	0.31 - 2.82	37	70.704
YZ2044	2000	44000	3.5	2.4 - 4	0.22 - 2.26	37	97.135
YZ2245	2200	45000	3.5	3.2 - 5.3	0.23 - 2.25	45	125.462
YZ2550	2500	50000	3.5	6.2 - 7.4	0.68 - 1.45	55	179.606
