Green 15kPa Horizontal Bed Roaster Electromagnetic Heating Vertical Bed Roaster

Green horizontal bed roaster

15kPa horizontal boiling roaster

electromagnetic heating vertical bed roaster

Place of Origin:

henan China

Brand Name:

Zoomline

Request A Quote

Product Details

Particle Size Range:

0.1 - 5Mm

Material:

Solid Particles

Scale-Up Potential:

High

Temperature Range:

300-1000°C

Uniformity Of Roasting:

High

Automation Level:

High

Operating Cost:

Low

Environmental Impact:

Low

Highlight:

Green horizontal bed roaster

15kPa horizontal boiling roaster

electromagnetic heating vertical bed roaster

Payment & Shipping Terms

Minimum Order Quantity

Price

Negotiable

Packaging Details

Wooden box or film

Delivery Time

30-50 days

Payment Terms

T/T

Supply Ability

Negotiable

Boiling Fluidized Bed Roasting 5m2 16m2 32m2 Custom Circulating Fluid Bed

Get Best Price

Video

Gold Concentrate Fluid Bed Incinerator Desulfurization Oxidation Fluidised Bed Incineration

Get Best Price

$Good price 5min Pyrite Fluid Bed Roaster Internal Refractory High Alumina Brick Industrial Roaster online$ Video

5min Pyrite Fluid Bed Roaster Internal Refractory High Alumina Brick Industrial Roaster

Get Best Price

Video

Environmentally Friendly Fluid Bed Roaster 30min Chemical Raw Materials Furnace

Get Best Price

86-0391

Contact Now

Product Description

Green 15kPa Horizontal/Vertical Bed Roaster with Electromagnetic Heating

Our fluidized bed calciner furnace utilizes advanced gas-solid fluidization technology to achieve uniform heat transfer and precise temperature control, making it ideal for continuous or batch processing of granular or powder materials. With modular design and automation features, it ensures high energy efficiency, reduced emissions, and scalable production.

Key Specifications

Attribute	Value
Particle Size Range	0.1 - 5mm
Material	Solid Particles
Temperature Range	300-1000°C
Uniformity Of Roasting	High
Automation Level	High
Operating Cost	Low
Environmental Impact	Low
Scale-Up Potential	High

Technical Parameters

Parameter	Value
Processing Capacity	0.5 to 50 tons per day (TPD)
Bed Layer Pressure Drop	5 to 15 kPa
Air Flow Rate	10-100 m/s
Residence Time	5-30 Minutes
Thermal Efficiency	≥85%
Reactor Material	310 Stainless Steel / Inconel Nickel Alloy / Corrosion-resistant ceramic lining

Available Models

Model	Diameter (mm)	Capacity (t/h)	Power (kW)	Weight (t)
ZLFT - 0.6m²	900	0.1 - 1.2	5.5 - 7.5	3.5
ZLFT - 1.1m²	1200	0.3 - 2.7	11 - 15	5.9
ZLFT - 3m²	2000	1.1 - 3.5	22 - 30	17
ZLFT - 5m²	2600	3.8 - 7.9	30 - 45	26
ZLFT - 16m²	4600	15 - 30	90 - 110	55
ZLFT - 32m²	6400	26 - 60	132 - 180	98

Core Applications

Metallurgical Industry: Oxidation/Sulfation calcination of ores (zinc, copper, nickel)
Chemical and Battery Materials: Roasting of lithium-ion battery cathode precursors
Environmental Engineering: Thermal desorption of contaminated soil
Advanced Materials: Synthesis of ceramic powders (Al2O3, SiC)
Energy and Food: Biomass pyrolysis, coffee beans/cocoa nibs roasting

Key Benefits

Energy Saving

Up to 30% reduction in fuel consumption compared to rotary kilns

Precision Control

Bed temperature deviation of ±2 degrees Celsius

Low Maintenance

No moving parts in the reaction zone

Custom Solutions

Turnkey service from lab-scale testing to full plant engineering

Customization Options

Our fluidized bed roasters can be customized for:

Size and capacity requirements
Atmosphere control (nitrogen/oxygen/argon)
Pressure settings (0.1 to 1.0 MPa)
Heating methods (electric/gas/indirect fuel combustion)

Technical Support

Our comprehensive support includes:

Installation and calibration assistance
Operator training programs
Equipment inspections and maintenance
Remote troubleshooting
Real-time data logging capability
