In today's society, waste treatment has become a global focus. Our waste incinerator, as an innovative environmental - friendly device, offers an ideal solution to the waste problem with its excellent performance and advanced technology.
This waste incinerator adopts a unique combustion method of "primary incineration + circumferential air mixing combustion + secondary pyrolysis gasification + burnout treatment". The primary incineration decomposes the waste initially. The circumferential air mixing combustion promotes full contact between the waste and air. The secondary pyrolysis gasification further improves the combustion efficiency, and the burnout treatment ensures complete combustion of the waste. This progressive combustion method greatly enhances the incineration effect.
It has numerous remarkable advantages. With an extremely high incineration efficiency, it can fully combust waste and effectively reduce the volume of waste. Meanwhile, the equipment is compact in size and occupies a small area, which is convenient for installation and use. It is suitable for various places, such as hospitals, hotels, stations, large commercial institutions, enterprises, and public institutions. Its wide application scope makes it a "versatile key" in the waste treatment field.
The fully - enclosed operation design is a major highlight of this incinerator. When handling infectious waste, it can effectively prevent secondary pollution, providing reliable protection for the environment and human health. In addition, it is available in two types: fuel - oil - fired and gas - fired. Users can choose flexibly according to actual needs to meet the requirements of different scenarios.
In terms of technical indicators, when treating domestic waste, the temperature in the incinerator can be stably maintained at ≥850°C, the residence time of flue gas is ≥2.0 seconds, the incineration efficiency is ≥99%, the destruction and removal rate is ≥99%, and the heat - reduction rate of incineration residues is ≥5%. All indicators meet or even exceed the national specified standards, fully demonstrating its high - efficiency harmless treatment capacity.
In terms of equipment specifications, we offer a variety of models, such as XJY - 30, XJY - 50, XJY - 100, etc. The incineration capacity of different models ranges from 30 - 50 kg/time to 400 - 500 kg/time. Parameters such as the size of the incinerator, the size of the garbage inlet, the specifications of the chimney, the power of the fan, the power of the burner, and the fuel consumption also vary. Users can select the most suitable model according to their own waste treatment volume and site conditions.
For installation, we provide detailed and convenient installation instructions. Whether it is the hoisting of the main equipment, the flue gas purification chamber, and the chimney, or the installation of the fan, burner, and oil pipeline, there are clear operating steps to ensure that users can complete the installation smoothly and put it into use quickly.
Choosing our waste incinerator means choosing an efficient, environmentally - friendly, and safe waste treatment method, contributing to environmental protection and sustainable development.
| Specification |
ZJS-30 |
ZJS-100 |
ZJS-200 |
ZJS-300 |
ZJS-500 |
| Handling Capacity (kg/times) |
30 - 80 |
100 - 150 |
200 - 300 |
300 - 400 |
400 - 550 |
| Size of Feeding Port (mm) |
480×600 |
760×960 |
900×1100 |
1080×1280 |
1300×1400 |
| Blower Power (kw) |
0.15 |
0.25 |
0.5 |
0.75 |
1.1 |
| Primary Burner |
Power: 0.17KW
Oil consumption: 4 - 6kg/h |
Power: 0.17KW
Oil consumption: 4.5 - 10kg/h |
Power: 0.17KW
Oil consumption: 6.5 - 14kg/h |
Power: 0.32kw
Oil consumption: 6.5 - 14kg/h |
Power: 0.32kw
Oil consumption: 6.5 - 14kg/h |
| Secondary Burner |
Power: 0.17KW
Oil consumption: 4 - 6kg/h |
Power: 0.17KW
Oil consumption: 4.5 - 10kg/h |
Power:
Oil consumption: |
Power:
Oil consumption: |
Power:
Oil consumption: |
| Weight (t) |
3.1 |
4.5 |
8.6 |
13.7 |
18.9 |
| Chimney (mm) |
273 |
273 |
